Autonics Model | BRP100-DDT-P | Photoelectrical Sensor

Name: Autonics Model | BRP100-DDT-P | Photoelectrical Sensor
SKU: 038338
Availability: InStock

LKR

USD

6,825.00 LKR

BRP Series

100mm sensing distance

NPN output

In Stock: 10
Can be backordered with delivery in 15 to 30 working days after order approval if out of stock.

SKU: 038338 Categories: BRP Series, Sensor, Sensors

Autonics Model | BRP100-DDT-P | Photoelectrical Sensor

Model: BRP100-DDT-P
Sensor type: Diffuse reflective photoelectric sensor
Sensing distance: 100 mm
Output type: PNP open collector
Operating voltage: 12–24 V DC ±10%
Response time: <1 ms
Operation mode: Selectable Light ON / Dark ON via control wire
Protection rating: IP66
Sensitivity adjustment: Manual adjuster
Operating temperature: -25°C to +55°C
Features:
- Narrow beam type for tight space detection
- High noise immunity via digital signal processing
- Reverse polarity and short-circuit protection
- LED indicator for operation status
Application: Object detection in packaging, robotics, and compact automation systems

If the requested quantity is available with us the product will be delivered within 3 working days if not product can be backordered and delivered within 3 to 4 weeks.
